Rawlbolt Loose Bolt M10/75L (Bag 5) RAWM1075LB - Rawlplug

General description The Rawlplug Rawlbolt Loose Bolt M10/75L is a versatile anchor designed for use in cracked and non-cracked concrete, hollowcore slabs, flooring blocks, and ceramics. It is particularly suitable for applications requiring fire resistance, providing reliable load support and safety across various substrates. This loose bolt features a three-piece expanding sleeve that maximizes expansion for optimal anchoring performance. Technical specifications Anchor Diameter: 10mm External Diameter: 16mm Overall Length: 140mm Max Fixture Thickness: 75mm Hole Diameter: 11mm Hole Diameter in Substrate: 16mm Installation Torque: 27 Nm Wrench Size: 17 Minimum Hole Depth in Substrate: 65mm Minimum Installation Depth: 60mm Minimum Substrate Thickness: 100mm Minimum Spacing: 50mm Minimum Edge Distance: 75mm Pack Quantity: Bag of 5 Installation Insert the bolt into a hole of 11mm diameter in the substrate. Ensure the hole depth is at least 65mm. Use a wrench size 17 to tighten the bolt
