Tbc - Norbar 180260 HT3-1000 Hand Torque Multiplier 100-1000NM

General description The Norbar HandTorque® HT3-1000 is designed for applications requiring higher torque levels that may be limited by space or operator strength. It features a robust and compact design, ensuring minimal maintenance and increased longevity. The tool is supplied with two reaction bar styles for maximum versatility, and it allows for a reaction in eight different orientations thanks to its quick change cranked reaction. Technical specifications Torque Range: 100-1,000Nm (74-738 lbf.ft) Drive: Output: 3/4in Square, Input: 1/2in Square Weight: 2.7kg Reaction Plate Weight: Cranked: 0.5kg, Straight: 0.69kg Nominal Torque Multiplication: 5:1 (reaction dependent) Accuracy: ±4% Ratio with Cranked Foot: 4.8:1 Ratio with Straight Reaction: 4.9:1 Usage Input to the multiplier is achieved via a ratchet torque wrench set to one fifth of the desired output torque.
